Wood Tech NCG 2812E is designed to outperform simple wood carving to significant production work with features rivalling top-level industrial-grade machines.
To minimise potentially harmful dust exposure to operators, our panel saw is integrated with a UFO102B Dust Collector that has an effective extraction point from the enclosed saw head.
Wood Tech NBC332S is designed to ensure optimal panel finishing. It is the perfect edgebander for workshops requiring continuous and high-quality edgebanding of panels.
The senator CS8 Rotary Screw Compressor packs a punch and is the perfect solution for your workshop. Not only does it supply air for your machinery but also keeps your work benches ready adequate steady air supply.
The Wood Tech MJ1132F Panel Saw is incredibly well-built and capable to meet the cutting needs in a workshop. Designed to offer ultimate precision, smoother operation, and the cleanest and most precise cuts possible. It means business!
Increasing productivity is key to any business, this machining centre will come equipped with an operational software that can be programmed to deliver precise cuts, and fast results.
Like any CNC machining centre, the NCG2812E is built for maximum performance inside and out. The sturdy mechanical design is complemented perfectly by the unique user-friendliness of the sophisticated machine parts. The reason for this is that we not only set standards in technology but also in operation.
SPECIFICATIONS
| Control system | SYNTEC |
| Working table | 2800 x 1200 mm |
| Max speed | 80/60/20 m/min |
| Main spindle power | 12HP ISO30 |
| Rotating speed | 1,000 - 24,000 RPM |
| Tool changer | 12 Positions |
| Drilling unit | 10 vertical drills (rotating speed 6,000 RPM) |
| Vacuum pump | 1 x 7.5 kW 305 m3/h |
| Dust extraction | Outlet:Ø200 mm Ø125mm *3 Speed required: 28 m/s |
| Power supply | Voltage: 3415V, 3-phase Frequency: 50 Hz |
| Total power | 25kW |
| Net weight | 3000kg |
The NBC332S Edgebander is already one of our customer's favourites. The best solution in edgebanding. This entry-level edgebanding machine is flexible, compact, and affordable, an ideal choice for modern craftsmen who strive for perfection with each project. Designed for maximum convenience, portability, and efficiency.
SPECIFICATIONS
| Control system | SYNTEC |
| Panel length | 120 mm |
| Panel width | 60 mm |
| Min panel size | 120 mm x 60 mm |
| Panel thickness | 9 mm - 60 mm |
| Edge tape | 0.4 mm - 3 mm |
| Track speed | 16/20/24 m/min |
| Control | Touchscreen |
| Dust outlet | 2 x 125 mm dia |
| Weight | 2100 kg |
| Power | 11.1kW |
| Dimensions | 3874 x 1335 x 1440 mm |
The sliding panel saw MJ1132F is the ideal entry into the premium compact class. It strikes a perfect balance between performance and price, as you would expect from an industrial-grade saw. Focused engineering combined with an operating technology reduced to the basics makes this panel saw an ideal partner for anyone who is looking for a reasonably priced introduction to the top division of sawing.
SPECIFICATIONS
| Control system | SYNTEC |
| Max cutting length | 3200mm |
| 0° max cutting thickness | 100mm |
| 45° max cutting thickness | 70mm |
| Main Saw | |
| Speed | 3800 - 5200 RPM |
| Motor | 5.5kw. 7 ½ HP |
| Scoring | |
| Speed | 9000 RPM |
| Motor | 1.1 kW |
| Saw blade tilting | 0 - 45° |
| Dust collection | 120mm diameter & 80mm on the overhead |
| Total power | 6.6 kW |
| Dimensions | 3300mm x 3370mm x 1200mm |
| Weight | 785 kg |
DUST EXTRACTOR UFO102B
To minimise potentially harmful dust exposure to operators, our panel saw is integrated with a UFO102B Dust Collector that has an effective extraction point from the enclosed saw head.
SPECIFICATIONS
| Model | UFO-105B |
| Motor | 7.5kW (10 HP), 415 Volt, 3 phase |
| Amps | 16 |
| Inlet diameter | 220 mm x 1 – (fan dia. 430mm) |
| Airspeed | 104 m³/min. (3673 CFM) |
| Bag volume | 0.75 m³ |
| Dimensions | Length: 1930 mm Width: 750 mm Height: 3300 mm |
| Net weight | 203 kg |
| Gross weight | 280 kg |
SENATOR CS8 ROTARY SCREW COMPRESSOR
No matter what the type or size of woodworking operation, compressors play an integral job in providing air for air-operated tools for low-cost operation.
SPECIFICATIONS
| Model | CS8 |
| Motor Power | 7.5 kW (10 HP) |
| Free Air Delivery | 1.10 m³/min (39 cfm) |
| Working Pressure | 8 bar (116 psi) |
| Optional Pressures | 7-10 bar (102-145 psi) |
| Tank Volume | 600 L |
| Noise Level | 68 dB(A) |
